The Southwire 22979957 is a 500-foot roll of 10 AWG stranded copper THHN building wire with orange insulation. This single-conductor building wire is designed for installation inside conduit, raceways, and approved cable tray systems in residential, commercial, and industrial electrical applications.
Constructed with a stranded annealed copper conductor, this wire provides improved flexibility for easier conduit pulls compared to solid conductors. The conductor is insulated with heat-resistant PVC and protected by a durable nylon jacket that offers resistance to abrasion, oil, gasoline, and moisture exposure.
THHN building wire is commonly used for branch circuits, feeder circuits, and general-purpose power distribution where individual insulated conductors are required within conduit systems. It carries a 600-volt rating and is suitable for dry locations at 90°C in accordance with National Electrical Code standards.
Specifications
• Type: THHN Building Wire
• Gauge: 10 AWG
• Conductor Material: Copper
• Stranded or Solid: Stranded
• Length: 500 Feet
• Color: Orange
• Voltage Rating: 600 Volts
• Temperature Rating: 90°C (Dry Location)
• Insulation: PVC with Nylon Jacket
• Installation Type: Conduit or Raceway
• UL Listed: Yes
Kyle –
The Southwire 10 AWG orange THHN wire came exactly as described. The 500-foot roll was clean, easy to handle, and the orange jacket made it simple to identify on the job. Good quality wire and fair pricing from IB Lighting.
Trevor –
This 10 AWG stranded copper THHN roll worked well for our electrical project. The wire was flexible, the insulation looked consistent, and the roll arrived in good condition. Free shipping made the order a better value.
Marcus –
Good Southwire quality and a smooth buying experience. The orange THHN jacket was clean, the stranded copper was easy to work with, and the 500-foot length was convenient for our job. IB Lighting had competitive pricing.
Patrick –
We ordered this Southwire 10 AWG orange THHN wire for stock, and it matched the listing perfectly. The material quality was dependable, the wire pulled cleanly, and customer service was responsive when we had a question.
Sean –
The 500-foot roll arrived ready to use and in good condition. The orange jacket helped keep the wiring organized, and the stranded copper made installation easier. Good product, good price, and shipping was included.
Ryan –
This Southwire 10 AWG stranded copper THHN wire was a solid purchase. The roll was consistent from start to finish, and the insulation quality looked good. IB Lighting made the order process simple and professional.
